Description
Product Overview
The 2 Channel Relay Module from ZHEJIANG GEYA is engineered for high‑performance industrial applications where reliability and compactness are essential. Constructed with a robust metal enclosure that meets TUV, UL, and RoHS standards, the module provides a durable platform for continuous operation in harsh environments. Each channel is capable of handling up to 10 A at 250 VAC or 30 VDC, delivering flexible power management for a wide range of loads. The relay contacts are designed for low contact resistance, ensuring efficient energy transfer and minimal heat generation.
Input connections are facilitated by screw‑terminal blocks, supporting both NPN and PNP transistor configurations as well as AC and DC control signals. This flexibility allows seamless integration with programmable logic controllers (PLCs), variable frequency drives (VFDs), and other automation equipment. The module operates on a 24 V AC/DC supply, making it compatible with standard industrial power rails while providing a safe voltage level for maintenance personnel.
Key physical specifications include a compact footprint of 3.58 × 2.64 × 2.05 inches and a lightweight design of just 3.21 ounces, enabling easy mounting on DIN rails in crowded control panels. The package includes LED status indicators for each channel, giving instant visual feedback on relay state, and built‑in surge suppression as well as over‑voltage protection to safeguard both the module and connected equipment.
Usage
This relay module is ideally suited for a variety of industrial automation scenarios. In manufacturing lines, it can control motor starters, solenoid valves, and heating elements, providing precise on/off control synchronized with PLC logic. For HVAC systems, the module can manage compressors, fans, and dampers, ensuring efficient climate regulation while protecting equipment from voltage spikes.
In renewable energy installations, such as solar inverters or wind turbine control panels, the 2 Channel Relay Module offers reliable switching for power conversion stages and safety interlocks. Its DIN rail mounting capability allows quick installation in standard control cabinets, and the LED indicators simplify troubleshooting during commissioning and routine maintenance.
Electrical engineers and system integrators appreciate the module’s ability to accept both AC and DC control signals, reducing the need for additional interface circuitry. The screw‑terminal wiring simplifies field installation, and the compact size frees up valuable panel space for additional components or future expansion.
Why Choose Us
Choosing ZHEJIANG GEYA means selecting a partner committed to quality, compliance, and customer support. Our relay modules undergo rigorous testing procedures, including thermal cycling, dielectric strength, and mechanical endurance tests, to guarantee performance over the product’s expected lifespan. The adherence to international safety certifications such as TUV and UL provides confidence that the module meets global standards for electrical safety.
We stand behind every unit with a comprehensive warranty and responsive technical assistance. Our engineering team is available to help with integration questions, wiring diagrams, and firmware compatibility, ensuring that your project proceeds without unnecessary delays. Additionally, we maintain an extensive inventory of spare parts, allowing quick replacements and minimizing downtime for critical systems.
Beyond the product itself, ZHEJIANG GEYA offers value‑added services such as custom labeling, bulk packaging options, and rapid shipping to meet the demands of large‑scale industrial projects. Our commitment to continuous improvement drives ongoing enhancements to relay performance, durability, and ease of use.
Key Features
- High current capacity of 10 A at 250 VAC or 30 VDC for versatile load handling
- Compact DIN rail design saves space and simplifies panel installation
- LED status indicators provide instant visual feedback for each channel
- Built‑in surge suppression and over‑voltage protection enhance system safety
- Dedicated customer support and warranty ensure reliable after‑sales service
FAQ
What voltage ranges can the relay module accept for control signals?
The module accepts both AC and DC control signals, typically ranging from 5 V to 24 V, allowing flexible integration with most PLCs and control circuits.
Can the relay be used in a 230 VAC environment?
Yes, the relay contacts are rated for up to 250 VAC, making the module suitable for 230 VAC applications when paired with the appropriate power supply.
Is the module compatible with NPN and PNP transistor outputs?
Absolutely. The input terminals support both NPN and PNP configurations, providing versatility for different control logic designs.
How does the surge protection work?
Each channel includes a built‑in metal‑oxide varistor (MOV) that clamps transient voltage spikes, protecting the relay contacts and downstream equipment from damage.
What is the recommended mounting method?
The module is designed for standard DIN rail mounting. Secure the rail in your control cabinet, snap the module onto the rail, and tighten the mounting screws for a firm, vibration‑resistant installation.
